20460048 Check Valve Outlet Poppet for waterjet intensifier pump
Win Win waterjet provide many kinds of waterjet parts, OEM/ODM available
20460048 is likely a specific part number for a waterjet check valve outlet poppet made by a manufacturer of waterjet equipment or accessories. A check valve is a type of valve that allows fluid to flow in one direction only, preventing backflow or reverse flow.
In a waterjet system, a check valve may be used to prevent water from flowing back into the high-pressure pump when the pump is turned off, which could cause damage to the pump. The outlet poppet of the check valve is the part that opens and closes to allow or prevent fluid flow.
The specific details of the "20460048 waterjet check valve outlet poppet" would depend on the manufacturer and model of the waterjet system for which it is designed. It is possible that the poppet is designed to fit a specific size or type of check valve or has other features or specifications that are specific to the manufacturer or model.
Item | Part Number | Description | Item | Part Number | Description |
1 | 20458305 | End Cap | 12 | 20458062 | Plunger Retainer |
2 | 20457399 | High Pressure Cylinder | 13 | 20458869 | Hydraulic Piston Assembly |
3 | 20458299 | End Bell, LH | 20457966 | Hydraulic Piston | |
4 | 20458302 | End Bell, RH | 20458821 | Rebuild Kit, Piston Rings | |
5 | 20458191 | Tie Rod | 20460216 | Seal | |
6 | 20460489 | Hex Nut | 14 | 20458170 | Spacer, Hydraulic Seal |
7 | 20457414 | Hydraulic Cylinder | 15 | 20458908 | Sealing Head Assembly |
8 | 20458161 | Backup Sleeve | 16 | 20460252 | Snap Ring |
9 | 20458773 | Rebuild Kit, High Pressure Seal Assembly | 17 | 05202930 | Snap Ring |
20457990 | Seal Buttress | 18 | 20457267 | Inlet Water Nipple | |
20458113 | High Pressure Seal | 20457159 | Adapter, Quick Disconnect | ||
20457393 | Seal Hoop | 20459025 | O-Ring, Quick Disconnect | ||
20460108 | O-Ring | 11 | 20457912 | Plunger | |
10 | 20458797 | Rebuild Kit, Hydraulic Seal Assembly |
