20459001 HP Cylinder Wrench for waterjet intensifier pump
Win Win waterjet provide many kinds of waterjet parts, OEM/ODM available
The Waterjet HP Cylinder Wrench 20459001 is a specialized tool designed to tighten or loosen the high-pressure cylinder on a waterjet system. Here are the general steps to use the wrench:
Turn off the waterjet system and disconnect the power supply.
Locate the high-pressure cylinder on the waterjet system. This may require referring to the manufacturer's manual or consulting with a technician.
Insert the wrench onto the cylinder nut, ensuring that the wrench is securely in place.
Turn the wrench clockwise to tighten the cylinder nut or counterclockwise to loosen it, using firm pressure. Take care not to overtighten or overtighten the nut, as this can damage the cylinder or the wrench.
Once you have tightened or loosened the cylinder nut to the desired level, remove the wrench from the nut.
Reconnect the power supply and turn on the waterjet system to test the cylinder's functionality.
Item | Part Number | Description | Item | Part Number | Description |
1 | 20458305 | End Cap | 12 | 20458062 | Plunger Retainer |
2 | 20457399 | High Pressure Cylinder | 13 | 20458869 | Hydraulic Piston Assembly |
3 | 20458299 | End Bell, LH | 20457966 | Hydraulic Piston | |
4 | 20458302 | End Bell, RH | 20458821 | Rebuild Kit, Piston Rings | |
5 | 20458191 | Tie Rod | 20460216 | Seal | |
6 | 20460489 | Hex Nut | 14 | 20458170 | Spacer, Hydraulic Seal |
7 | 20457414 | Hydraulic Cylinder | 15 | 20458908 | Sealing Head Assembly |
8 | 20458161 | Backup Sleeve | 16 | 20460252 | Snap Ring |
9 | 20458773 | Rebuild Kit, High Pressure Seal Assembly | 17 | 05202930 | Snap Ring |
20457990 | Seal Buttress | 18 | 20457267 | Inlet Water Nipple | |
20458113 | High Pressure Seal | 20457159 | Adapter, Quick Disconnect | ||
20457393 | Seal Hoop | 20459025 | O-Ring, Quick Disconnect | ||
20460108 | O-Ring | 11 | 20457912 | Plunger | |
10 | 20458797 | Rebuild Kit, Hydraulic Seal Assembly |
