20443831 pressure gauge for 100HP waterjet cutting pump
Win Win waterjet provide many kinds of waterjet parts, OEM/ODM available
The 20443831 pressure gauge is a component used to measure high-pressure water flow pressure in a water spray pump. The pressure gauge is usually located on the control panel or high-pressure cylinder of the pump and is responsible for providing visual indication of water flow pressure.
The function of a pressure gauge is to provide a quick and convenient method to monitor the pressure of high-pressure water flow. Pressure gauges typically consist of a dial or digital display that displays water flow pressure in pounds per square inch (PSI) or other pressure units.
By monitoring the pressure gauge, the operator can ensure that the water jet pump operates at the correct pressure of the material being cut, which helps to ensure cutting quality and prevent damage to the pump or workpiece. The pressure gauge can also be used to detect any abnormal pump pressure, which may indicate a malfunction or problem with the pump.
Overall, the pressure gauge is a key component of a water jet pump as it helps provide a quick and convenient method to monitor the pressure of high-pressure water flow. If there is no working pressure gauge, the operator will not be able to monitor the water flow pressure, which may lead to pump performance degradation or even pump failure.
Item | Part Number | Description | Item | Part Number | Description |
1 | 72119536 | HP Cylinder | 16 | 05120092 | Backup Ring, 5.25 x 5.50 |
2 | 05144506 | Ceramic Plunger | 17 | 10074771 | O-Ring, 5.25 x 5.50 x .13 |
3 | 72110979 | Sealing Head Assembly | 18 | 20413955 | Socket Head Screw, 3/4-16 x 3-1/4 |
4 | 20416445 | Hydraulic Cylinder Head | 19 | 05130224 | Proximity Switch, 20-250V AC/DC |
5 | 05149711 | HP Seal Assembly | 20 | 95119012 | Socket Head Screw, 1/4 x 20 x 1 |
7 | 49838220 | HP Cylinder Nut, HSEC | 21 | 05146576 | Piston Assembly |
8 | 05146584 | Hydraulic Cartridge Seal Assembly | 23 | 05144522 | Topworks Support |
9 | 05145099 | Bushing Retainer Flange | 25 | 05041058 | Socket Head Screw, 3/8-16 x 2-1/4 |
11 | 72110945 | Liner, HP Cylinder | 26 | 95688743 | Lock Washer, .38 |
12 | 10074920 | O-Ring, 1.75 x .94 x .09 | 27 | 10118206 | O-Ring, 1.31 x 1.56 x .13 |
13 | 80070352 | Jackbolt, 7/16-20 x 2.31 | 28 | 05144183 | Spacer Assembly, Proximity Switch |
14 | 05034798 | Retaining Ring | 05144191 | O-Ring, .69 x .88 x .09 | |
15 | 05144514 | Hydraulic Cylinder | 29 | 05146592 | Gasket, Topworks Support |
