20437164 electrical shift pilot assembly for 100HP waterjet cutting pump

Win Win waterjet provide many kinds of waterjet parts, OEM/ODM available

20437164 Electrical Shift Pilot Assembly is a component used in a water jet pump to control the movement of the pump plunger from forward to reverse. The electric shift pilot assembly is usually located on the control panel of the pump, responsible for receiving electrical signals from the pump control system and using these signals to move the pump plunger.

The function of the electric shift pilot component is to provide a reliable and precise control mechanism for moving the pump plunger from forward to reverse. This component typically consists of multiple components, including a solenoid valve, a pilot valve, and a pressure switch, which work together to control the movement of the plunger.

When the control system of the pump sends an electrical signal to the electric shift pilot component, the solenoid valve opens, causing high-pressure water to flow towards the pilot valve. Then, the pilot valve uses the pressure of water flow to move the plunger of the pump from forward to reverse.

If the electric shift pilot component is damaged or malfunctioning, it may cause the plunger of the pump to move improperly or not shift at all, leading to a decrease in pump performance or even pump failure. Therefore, it is important to replace the electric shift pilot component once there are signs of wear or damage to ensure the safe and efficient operation of the water spray pump.

Overall, the electric shift pilot assembly is a key component of the water jet pump, as it helps to accurately and reliably control the movement of the pump plunger. If there is no normally operating electric shift pilot component, the water jet pump will not be able to operate effectively, and the cutting quality will also be affected.
