Low Mass Orifice
 | Duraflow Orifice Part number Diameter 014155-10 .01 Inch 014155-11 .011 Inch 014155-12 .012 Inch 014155-13 .013 Inch 014155-14 .014 Inch 014155-15 .015 Inch 014155-16 .016 Inch 014155-7 .007 Inch |
Low Mass Orifice
 | Part number Diameter 003788-10 .010 Inch 003788-4 .004 Inch 003788-5 .005 Inch 003788-6 .006 Inch 003788-7 .007 Inch 003788-9 .009 Inch |
Instajet Diamond Orifice Part number: D-5070-7
 | Instajet Orifice Part number Diameter 001821-10 .010 Inches 001821-11 .011 Inches 001821-12 .012 Inches 001821-13 .013 Inches 001821-4 .004 Inches 001821-6 .006 Inches 001821-7 .007 Inches 001821-8 .008 Inches 001821-9 .009 Inches |
 | Diamond Orifice Part number Diameter 015849-10 .010 Inch 015849-12 .012 Inch 015849-13 .013 Inch 015849-14 .014 Inch 015849-15 .015 Inch 015849-7 .007 Inch |
Ruby Orifice
 | Part number Diameter 041759-10 .010 Inch 041759-11 .011 Inch 041759-12 .012 Inch 041759-13 .013 Inch 041759-14 .014 Inch 041759-15 .015 Inch 041759-16 .016 Inch 041759-17 .017 Inch 041759-5 .005 Inch 041759-7 .007 Inch 041759-8 .008 Inch 041759-9 .009 Inch |
Paser ECL Ruby Orifice
 | Part number Diameter 014201-10 .010 Inches 014201-11 .011 Inches 014201-12 .012 Inches 014201-13 .013 Inches 014201-14 .014 Inches 014201-15 .015 Inches 014201-16 .016 Inches 014201-18 .018 Inches 014201-7 .007 Inches 014201-8 .008 Inches 014201-9 .009 Inches |
Type D Orifice Assembly Part number Diameter 300250-18 .018 Inches 300250-21 .021 Inches 300250-25 .025 Inches | Water Only Diamond Orifice Part number Inner Diameter D-5071-10 .010 Inch D-5071-14 .014 Inch D-5071-4 .004 Inch D-5071-5 .005 Inch D-5071-6 .006 Inch D-5071-7 .007 Inch D-5071-8 .008 Inch |
1. AUTOLINE PRO 6,200 bar Diamond Orifice
 | 0.004" / 0.10 mm 20481704 0.005" / 0.12 mm 20481705 0.006" / 0.15 mm 20481706 0.007" / 0.17 mm 20481707 0.008" / 0.20 mm 20481708 0.009" / 0.23 mm 20481709 0.010" / 0.25 mm 20481710 0.011" / 0.28 mm 20481711* 0.012" / 0.30 mm 20481712 0.013" / 0.33 mm 20481713* 0.014" / 0.35 mm 20481714 0.015" / 0.38 mm 20481715* 0.016" / 0.40 mm 20481716 0.017" / 0.43 mm 20481717* 0.018" / 0.46 mm 20481718* 0.019" / 0.48 mm 20481719* 0.020" / 0.51 mm 20481720* 0.021" / 0.53 mm 20481721* 0.022" / 0.56 mm 20481722* |
2. AUTOLINE I & II 4,100 bar For True Alignment & Maximum Performance waterjet cutting head Diamond Orifice
  | 0.004" / 0.10 mm 20448625* 0.007" / 0.17 mm 05063847 0.008" / 0.20 mm 05112537 0.009" / 0.23 mm 05084504 0.010" / 0.25 mm 05077029 0.011" / 0.28 mm 05101753 0.012" / 0.30 mm 05077300 0.013" / 0.33 mm 05136098 0.014" / 0.35 mm 05077037 0.015" / 0.38 mm 80075781* 0.016" / 0.40 mm 05121512 0.018" / 0.46 mm 05114905* 0.019" / 0.48 mm 80086663* 0.020" / 0.51 mm 05114897 |
3. Sapphire Orifice
  | 0.007" / 0.17 mm 05109079* 0.008" / 0.20 mm 05109087* 0.009" / 0.23 mm 05109095* 0.010" / 0.25 mm 05109103* 0.011" / 0.28 mm 05109111* 0.012" / 0.30 mm 05109129* 0.013" / 0.33 mm 20412569* 0.014" / 0.35 mm 05109137* 0.016" / 0.40 mm 20448541* 0.018" / 0.46 mm 05114913* 0.019" / 0.48 mm 80086671* 0.020" / 0.51 mm 05114921 |
4. Orifices for Pure Water Cutting 4,100 bar Diamond Orifice
  | 0.003" / 0.07 mm 49888852 0.004" / 0.10 mm 49888860 0.005" / 0.12 mm 49888878 0.006" / 0.15 mm 49888886 0.007" / 0.17 mm 49888894 0.008" / 0.20 mm 49888902 0.009" / 0.23 mm 49888910 0.010" / 0.25 mm 49888928 0.012" / 0.30 mm 49888936 0.013" / 0.33 mm 49836786* 0.014" / 0.35 mm 49888944 0.015" / 0.38 mm 49888951 0.016" / 0.40 mm 49888969 0.018" / 0.46 mm 49888977 0.019" / 0.48 mm 20436198* 0.020" / 0.51 mm 49888985 0.022" / 0.56 mm 49888993 |
5. waterjet cutting head Sapphire Orifice
  | 0.003" / 0.07 mm A2260003* 0.004" / 0.10 mm 49863574 0.005" / 0.12 mm 49863582 0.006" / 0.15 mm 91954073 0.007" / 0.17 mm 49863590 0.008" / 0.20 mm 49865850 0.009" / 0.23 mm 49863608 0.010" / 0.25 mm 49863616 0.011" / 0.28 mm A2260011* 0.012" / 0.30 mm 49863624 0.013" / 0.33 mm A2260013* 0.014" / 0.35 mm 49863632 0.015" / 0.38 mm A2260015 0.016" / 0.40 mm A2260016 0.018" / 0.46 mm A2260018* 0.019" / 0.48 mm A2260019* 0.020" / 0.51 mm A2260020* 0.022" / 0.56 mm A2260022* |
6.4,100 bar Diamond Orifice
  | 0.005" / 0.12 mm 72113688 0.006" / 0.15 mm 72132350 0.007" / 0.17 mm 72113753 0.007" / 0.17 mm, 3/8-24 Thread 72113680 0.008" / 0.20 mm 72132358 0.009" / 0.23 mm 72136231 0.010" / 0.25 mm 72136249 0.011" / 0.28 mm 72136256 |
