AT01380 Plunger for ultra-high pressure pump K22A 100000 psi
Win Win waterjet provide many kinds of waterjet parts, OEM/ODM available
The 72162253 Ceramic Plunger is an assembly for Ultra High Pressure (UHP) waterjet pumps that operate at pressures up to 90,000 psi. The plunger is the key component of the pump responsible for generating high-pressure water for cutting, cleaning and other applications.
Ceramic plungers are commonly used in UHP waterjet pumps because of their ability to withstand the high pressure and abrasiveness of waterjet flow. Ceramic materials are generally harder and more wear-resistant than metal alloys, making them ideal for high-pressure applications.
If you would like to purchase this specific part, please contact win win waterjet, we are a professional manufacturer of waterjet cutting equipment with 20 years of experience in the industry and can customize upon request. Specializing in the production of high-end water cutting equipment and accessories.
Item | Part Number | Description | Item | Part Number | Description |
1 | 5146592 | Gasket, Topworks Support | 14 | 72162253 | Plunger |
2 | 20476377 | Support, Topworks | 15 | 5130091 | Hydraulic Seal Cartridge |
3 | 10118206 | O-Ring, 1.31×1.56× .13 | 16 | 72175989 | Bushing Retainer Flange |
4 | 5144514 | Hydraulic Cylinder | 17 | 72158494 | UHP Seal Assembly |
5 | 5098991 | Socket Head Screw, 3/8-16×3-3/4 | 18 | 72166738 | UHP Cylinder |
6 | 95688743 | Lock Washer, .38 | 19 | 72163802 | Liner |
7 | 72101190 | Piston Assembly | 20 | 20474325 | Stud, 1-1/8-12×18.31 |
8 | 10074771 | O-Ring, 5.25×5.50× .13 | 21 | 72170157 | Sealing Head Assembly |
9 | 5120092 | Backup Ring, 5.25×5.50× .13 | 22 | 72178493 | Flange Assembly |
10 | 72175997 | Hydraulic Cylinder Head | 23 | 20464590 | Flat Washer, 1.13 |
11 | 5097886 | Socket Head Screw, 3/4-16×2-1/4 | 24 | 20461761 | Hex Nut, 1-1/8-12 |
12 | 5144183 | Spacer Assembly, Proximity Switch | 25 | 20489339 | Adapter, JIC/Pipe, 50× .38 |
5144191 | O-Ring, .69× .88× .09 | 26 | 72176756 | O-Ring, 3.88×4.25× .19 | |
13 | 72141569 | Kit, Proximity Switch | 95119012 | Socket Head Screw, 1/4-20×1 | |
72134224 | Proximity Switch |
