K-MT Steamline SL-IV 50 HP waterjet pump parts

The WINWIN Waterjet Steamline SL-IV 50 HP waterjet pump parts incorporates over 50 years of experience offering unparalleled waterjet cutting technological achievements. From the proven performance of our threaded high-pressure cylinders which eliminates any misalignment during assembly, to our leading-edge hydraulic control valve design that provides seamless, lag free topworks shifting, the Steamline Series of pumps are Best in Class.

 SL-VI 1.jpg


Parts NumberParts Name
05144209END FLANGE
05144688SEALING HEAD ASSEMBLY
05144696SEALING HEAD SPACER
05144712CYLINDER LINER
10069904HEAVY HEX NUT
05144753PIN BOLT STUD
05144225FLANGE RING
05149703SEAL ASSEMBLY
05144647CYLINDER BODY
SL IV 2.jpg
Parts NumberParts Name
05034798SNAP RING
05007786FLANGE
05130091HYDRAULIC CARTRIDGE
05141106HYDRAULIC HEAD SCREW
05147913HYDRAULIC CYLINDER HEAD
05034855BACKUP RING
10075000O-RING
05119151CERAMIC PLUNGER
05132253PISTON ASSEMBLY
05034764HYDRAULIC CYLINDER
05127854PROXIMITY SWITCH
05049812MOUNTING STEM


 SL-IV 3.jpg


Parts NumberParts Name
05132261RAM PISTON
05074380RETAINING PIN
05049887HEX PLUG
10148757CHECK VALVE
05088364SNAP RING
05049994BACKUP RING
05087713O-RING
05117965SEAL ASSEMBLY
05117940GLIDE RING
SL-IV 4.jpg
Parts NumberParts Name
05144670Poppet Retainer
49884562Inlet Compression Spring
05144662Inlet Poppet
05144357Sealing Head Body
05112768HP Seat
05116561HP Poppet
05147863Compression Spring
05116751Poppet Pin
05116777Sealing Head Gland



SL-IV 5.jpg
Parts NumberParts Name
49888035SOLENOID VALVE
49894199PNEUAMTIC VALVE CYLINDER
10189181PNEUMATIC VALVE BODY
498645643/8”ADAPTER
49864309ADAPTER 9/16 TO 1/4″
49865843STEM
10187250SST BACKUP RING
10188233BACKUP RING
10178978SEAL ASSEMBLY 0.25
10178697SEAT
SL-IV 6.jpg
Parts NumberParts Name
10084440PURE GOOP
10148674HP SEALINSTALLATION TOOL
20484961VEE BLOCK CRADLE
80078300SEAL REMOVAL TOOL STAND
20477460PLUNGER REMOVAL TOOL
05066139CYLINDER WRENCH
05067350SEAL POSITIONING TOOL
49833114SEAL POSITIONING TOOL
20470413SEAL PUSH TOOL SEAL
20470417SEAL INSTALLATION TOOL

If you wanna know more about WINWIN Streamline SL-IV 50 HP waterjet pump parts,please contact me for the parts list.
