80086622 Hydraulic Cartridge Assembly kmt waterjet parts

Product Item：80086622

Product Name：Hydraulic Cartridge Assembly
Applying : Hydraulic Seal Cartridge, HP, .875 Plunger, 55K, 60K. Used in Jetline 30 and 50 HP units and E-Series 30 and 50HP units
Part number: #80086622

Product Detail

80086622 Hydraulic Cartridge Assembly kmt waterjet parts

05130091 seal.jpg

Item	Part Number	Description
1	80086630	Seal bushing
2	05015060	Packing ring
3	10193522	O-ring 1.19x1.38x.09
4	05050760	Backup ring 1.188x1.375
5	05129481	Backup ring 1.0x1.13x.06
6	05013024	O-ring 1.25x1.38x.06
7	05129515	Backup ring, 1.127x.891
8	05027255	Packing seal, U-cap
