72110979 Sealing Head Assembly for SL-VI100HP

72110979 Sealing Head Assembly for SL-VI100HP

Product Item:72110979 Sealing Head Assembly
Name:100HP waterjet pump spare part
Manufacturer: Win Win waterjet
  • Product Detail

72110979 Sealing Head Assembly for SL-VI100HP

Win Win waterjet provide many kinds of waterjet parts, OEM/ODM available


The 72110979 Sealing Head Assembly is a critical component in some types of waterjet pumps used for high-pressure water applications. Its primary function is to create a seal between the pump's plunger and the HP Cylinder, preventing water from leaking out of the cylinder during operation.


The sealing head assembly typically consists of a sealing head, a set of seals, and other necessary components such as bearings and retaining rings. When the pump's plunger moves forward, it creates a high-pressure pulse of water that is then forced into the HP Cylinder. The sealing head assembly is designed to create a tight seal between the plunger and the cylinder, preventing water from leaking out and ensuring that the high-pressure water flow is delivered to the application with maximum efficiency.


The 72110979 Sealing Head Assembly is typically made of high-strength materials such as stainless steel or other alloys that can withstand the high pressure and corrosive properties of the water being pumped. It is also designed to be highly durable and resistant to wear and tear, helping to ensure reliable and efficient operation of the waterjet pump.


Win Win waterjet has 20 years of experience in the cutting industry. Its products include: waterjet robotic cutting system, feeding waterjet cutting machine, portable waterjet cutting machine, booster pump, and multi-brand waterjet accessories. We only produce high-quality products and serve global customers. Our products are exported to 100 countries and regions, and have been well received and affirmed by customers.


100hp waterjet.png

ItemPart
Number
Description ItemPart
Number
Description
172119536HP Cylinder 1605120092Backup Ring, 5.25 x 5.50
205144506Ceramic Plunger1710074771O-Ring, 5.25 x 5.50 x .13
372110979Sealing Head Assembly 1820413955Socket Head Screw, 3/4-16 x 3-1/4
420416445Hydraulic Cylinder Head1905130224Proximity Switch, 20-250V AC/DC
505149711HP Seal Assembly2095119012Socket Head Screw, 1/4 x 20 x 1
749838220HP Cylinder Nut, HSEC2105146576Piston Assembly
805146584Hydraulic Cartridge Seal Assembly2305144522Topworks Support
905145099Bushing Retainer Flange 2505041058Socket Head Screw, 3/8-16 x 2-1/4
1172110945Liner, HP Cylinder 2695688743Lock Washer, .38
1210074920O-Ring, 1.75 x .94 x .092710118206O-Ring, 1.31 x 1.56 x .13
1380070352Jackbolt, 7/16-20 x 2.31 2805144183Spacer Assembly, Proximity Switch
1405034798Retaining Ring
05144191O-Ring, .69 x .88 x .09
1505144514Hydraulic Cylinder2905146592Gasket, Topworks Support


PREVIOUS:72110961 Sealing Head Body for SL-VI100HP pump

NEXT:05146576 Piston Assembly for SL-VI100HP
