72110953 Poppet Retainer
Win Win waterjet provide many kinds of waterjet parts, OEM/ODM available
The 72110953 Poppet Retainer is a component used in waterjet pumps to secure the poppet valve in place within the pump's high-pressure cylinder. The poppet valve is a small, spring-loaded valve that helps to regulate the flow of water through the pump.
The function of the Poppet Retainer is to hold the poppet valve securely in place within the pump's cylinder, preventing it from moving or coming loose during operation. The retainer is typically installed above the poppet valve and is designed to keep the valve seated properly within the cylinder.
If the Poppet Retainer becomes damaged or worn, it can cause the poppet valve to move or become loose, which can result in reduced pump performance or even pump failure. Therefore, it's important to replace the Poppet Retainer as soon as it shows signs of wear or damage to ensure that the waterjet pump operates safely and efficiently.
Item | Part Number | Description | Item | Part Number | Description |
1 | 72119536 | HP Cylinder | 16 | 05120092 | Backup Ring, 5.25 x 5.50 |
2 | 05144506 | Ceramic Plunger | 17 | 10074771 | O-Ring, 5.25 x 5.50 x .13 |
3 | 72110979 | Sealing Head Assembly | 18 | 20413955 | Socket Head Screw, 3/4-16 x 3-1/4 |
4 | 20416445 | Hydraulic Cylinder Head | 19 | 05130224 | Proximity Switch, 20-250V AC/DC |
5 | 05149711 | HP Seal Assembly | 20 | 95119012 | Socket Head Screw, 1/4 x 20 x 1 |
7 | 49838220 | HP Cylinder Nut, HSEC | 21 | 05146576 | Piston Assembly |
8 | 05146584 | Hydraulic Cartridge Seal Assembly | 23 | 05144522 | Topworks Support |
9 | 05145099 | Bushing Retainer Flange | 25 | 05041058 | Socket Head Screw, 3/8-16 x 2-1/4 |
11 | 72110945 | Liner, HP Cylinder | 26 | 95688743 | Lock Washer, .38 |
12 | 10074920 | O-Ring, 1.75 x .94 x .09 | 27 | 10118206 | O-Ring, 1.31 x 1.56 x .13 |
13 | 80070352 | Jackbolt, 7/16-20 x 2.31 | 28 | 05144183 | Spacer Assembly, Proximity Switch |
14 | 05034798 | Retaining Ring | 05144191 | O-Ring, .69 x .88 x .09 | |
15 | 05144514 | Hydraulic Cylinder | 29 | 05146592 | Gasket, Topworks Support |
