05116751 Poppet Pin for waterjet intensifier pump
Win Win waterjet provide many kinds of waterjet parts, OEM/ODM available
The function of a waterjet poppet pin, part number 05116751, is to secure the poppet valve in a waterjet cutting system. A poppet valve is a type of valve used in high-pressure pumps to control the flow of fluid by using a disc or cone-shaped element that sits on a seat.
In a waterjet cutting system, the poppet pin is used to hold the poppet valve in place within the valve body. The pin is typically inserted through a hole in the valve body and through the center of the poppet valve, securing the valve in place.
The poppet pin must be made of materials that can withstand the high pressures and forces present in the waterjet cutting system. It must also be precisely machined to ensure a perfect fit with the valve body and the poppet valve.
Overall, the function of the waterjet poppet pin is to provide a secure and reliable attachment point for the poppet valve in a waterjet cutting system, ensuring that the valve operates smoothly and efficiently. The part number 05116751 refers to a specific poppet pin component, and the specific function of this component would depend on the particular waterjet cutting system in which it is used.
Item | Part Number | Description | Item | Part Number | Description |
1 | 20458305 | End Cap | 12 | 20458062 | Plunger Retainer |
2 | 20457399 | High Pressure Cylinder | 13 | 20458869 | Hydraulic Piston Assembly |
3 | 20458299 | End Bell, LH | 20457966 | Hydraulic Piston | |
4 | 20458302 | End Bell, RH | 20458821 | Rebuild Kit, Piston Rings | |
5 | 20458191 | Tie Rod | 20460216 | Seal | |
6 | 20460489 | Hex Nut | 14 | 20458170 | Spacer, Hydraulic Seal |
7 | 20457414 | Hydraulic Cylinder | 15 | 20458908 | Sealing Head Assembly |
8 | 20458161 | Backup Sleeve | 16 | 20460252 | Snap Ring |
9 | 20458773 | Rebuild Kit, High Pressure Seal Assembly | 17 | 05202930 | Snap Ring |
20457990 | Seal Buttress | 18 | 20457267 | Inlet Water Nipple | |
20458113 | High Pressure Seal | 20457159 | Adapter, Quick Disconnect | ||
20457393 | Seal Hoop | 20459025 | O-Ring, Quick Disconnect | ||
20460108 | O-Ring | 11 | 20457912 | Plunger | |
10 | 20458797 | Rebuild Kit, Hydraulic Seal Assembly |
