Waterjet Parts Coil 10411 Coil Axis 4 5 6 Upper IRB 2400 UP20

Product Item：10413

Details: used on ABB IRB 2400 robot waterjet cutting system
Replacement robotic water jet coils are made in house and ship SAME DAY they are ordered.
Each coil is:
Made from 66K PSI or 100K PSI Tubing
Pre-Coned and Threaded
Flushed under High Pressure prior to ship

With over 20 years of experience, WINWIN Waterjet has a large archive of coil drawings including:
ABB,FANUC,YASKAWA,KUKA Coils
Shape Process Automation (DRS, KMT, RPT) Coils
Flow Robotics Coils

REPLACEMENT Robotic Waterjet parts Coil 10411

Robotic Waterjet parts Coil 10411 Description

10411 Coil Axis 4,5,6 Upper IRB 2400 Robotics Water jet and Coils

Item number: 10411

Details: Robotic Waterjet parts Coil 10411 used on ABB IRB 2400 Axis 4,5,6 robot waterjet cutting system

What is Waterjet cutting?

Waterjet cutting, often referred to as waterjet machining, is a versatile and precise industrial cutting process that uses a high-pressure stream of water, sometimes mixed with abrasive particles, to cut and machine a wide range of materials. The fundamental principle of waterjet cutting involves pressurizing water and directing it through a small orifice at very high speed, creating a focused jet of water. The primary types of waterjet cutting are pure waterjet cutting and abrasive waterjet cutting:

Pure Waterjet Cutting: In pure waterjet cutting, the high-pressure water jet is used to cut soft materials like rubber, foam, paper, textiles, and certain plastics. It is a cold cutting process, meaning it doesn't generate heat during cutting. Pure waterjet cutting is often used in applications where maintaining material integrity and preventing heat-affected zones are critical.

Abrasive Waterjet Cutting: In abrasive waterjet cutting, abrasive particles (usually garnet) are introduced into the high-pressure water stream. This mixture creates an abrasive waterjet, which is capable of cutting through hard materials such as metals, ceramics, glass, stone, composites, and more. The abrasive waterjet process significantly increases cutting power and versatility.

The key components of a waterjet cutting system typically include:

High-Pressure Pump: This pump pressurizes water to extremely high levels, typically in the range of 60,000 to 90,000 pounds per square inch (psi). The pump is responsible for generating the high-pressure water used in cutting.

Cutting Nozzle: The high-pressure water or abrasive water mixture is focused through a cutting nozzle that directs the jet onto the material to be cut. The nozzle is typically computer-controlled for precision cutting.

CNC Control System: Many waterjet cutting machines are computer numerically controlled (CNC), allowing for precise and automated control of the cutting process. This enables intricate and complex cuts to be made.

Abrasive Hopper (for abrasive waterjets): If it's an abrasive waterjet system, an abrasive hopper is used to introduce and mix the abrasive material with the high-pressure water.

Waterjet cutting is widely used in various industries, including aerospace, automotive, architecture, manufacturing, and more. It is known for its ability to cut a wide range of materials with precision and without heat-affected zones, making it a valuable tool for applications where material preservation and precision are critical.

If you are looking for robot waterjet cutting system suppliers or Robotic Water jet Coils suppliers, as well as waterjet technical support needs related to water cutting, please feel free to contact us, we can provide free online support for you.
