Robot Waterjet Cutting System System Description

The robotic water cutting system has a sitting, upside down, and flip structure.

It is equipped with a robot arm, a cutting work platform, a tooling fixture (prepared by the customer), a high-pressure pump, a vacuum adsorption system, a safety guardrail, a Water Filtration System, and a chiller. , the robot water cutting project object is the cutting of automobile interior parts, such as car roof cutting, car floor mat cutting, car door panel cutting, etc. The specific size needs to be determined according to the specific situation.

Robot system:

Cutting robot ABB 4600, weighing 20kg, is a commonly used robot model in robot waterjet cutting. It is suitable for seated installation, including control system and system connection assembly. It is suitable for cutting car roof panels. It has a large cutting range and can be installed normally.

The structure has two stations A and B that work alternately. The robot system, including the robot control system, uses ABB original equipment. Maintenance and quality assurance are undertaken by ABB’s official after-sales service.

Robot waterjet cutting peripheral facilities:

According to general project experience, robot waterjet cutting tooling fixtures are provided by the customer. Because each cutting tooling fixture is different, the customer needs to communicate with the car manufacturer about the cutting tooling fixture problem. There are many companies in China that can provide automotive cutting fixtures. WINWIN has a cooperative factory that produces automotive interior cutting fixtures. Customers can contact us if they need them.

Fixed work platform:

The fixed work platform is provided by WINWIN. This workbench is connected to the customer's cutting tool fixture, so the positioning structure and size of the fixed work platform need to be determined in advance. Generally speaking, This is basically standard. WINWIN company has multiple cases for customers to refer to and choose. Winwin company can give customers enough support to understand the technical parameters and some precautions related to robot water cutting. Customers are welcome to come for consultation.

Vacuum adsorption system:

This is an indispensable part of the robot water cutting workstation. This part is provided by winwin company. A vacuum adsorption machine with sufficient power can ensure the effective fixation of cutting accessories and the removal of impurities.

A good vacuum adsorption machine has tiny Noise, reducing the noise of vacuum adsorption machines is also a technology. At present, the vacuum adsorption machines designed by WINWIN company can reduce the noise to a minimum while ensuring sufficient power. Ensuring the working environment of workers is an aspect that WINWIN company has always paid great attention to.

WINWIN company has always attached great importance to it. A lot of humanized operations have been added to the design of the robotic water cutting workstation, which has won praise from customers in many aspects.

WINWIN is a professional manufacturer of robotic water cutting workstations, mastering the core technology and experience of robotic water cutting workstations. Provide customers with the best water cutting services!

If you are looking for robot waterjet cutting system suppliers or Waterjet parts Coil  suppliers, as well as waterjet technical support needs related to water cutting, please feel free to contact us, we can provide free online support for you.
