BV601184 Pneumatic Valve/Actuator Assembly, Normally Open Cylinder Head

Product Item：

20427648	Valve Body
10178697	Valve Seat
49830904	Adapter, HP Water Valve
20435636	Valve Stem
10188233	Backup Ring, Brass
20428052	Seal Assembly
10189553	Actuator Assembly, Normally Open
BV401184	Pneumatic Cylinder
BV601184	Cylinder Head
BV501184	Piston
10187250	Backup Ring, SST
10074714	O-Ring, 2.44 x 2.63 x .09
10074565	O-Ring, 2.25 x 2.38 x .06
Pneumatic Valve/Actuator Assembly, Normally Open Cylinder Head BV601184

Product Detail

Pneumatic Valve/Actuator Assembly, Normally Open 20427739
Item	Part Number	Description	Quantity
1	20427648	Valve Body	1
2	10178697	Valve Seat	1
3	49830904	Adapter, HP Water Valve	1
4	20435636	Valve Stem	1
5	10188233	Backup Ring, Brass	1
6	20428052	Seal Assembly
	10189553	Actuator Assembly, Normally Open
7	BV401184	Pneumatic Cylinder	1
8	BV601184	Cylinder Head	1
9	BV501184	Piston	1
10	10187250	Backup Ring, SST	1
11	10074714	O-Ring, 2.44 x 2.63 x .09	1
12	10074565	O-Ring, 2.25 x 2.38 x .06	2
