72178493 water jet cutter part Flange Assembly for 90000psi waterjet pump
Win Win waterjet provide many kinds of waterjet parts, OEM/ODM available
A waterjet with a pressure of 90,000 psi (pounds per square inch) is considered a high-pressure waterjet. High-pressure waterjets are used in various industries for cutting, cleaning, and stripping surfaces.
Here are some reasons why a 90,000 psi waterjet might be necessary:
Cutting thick materials: A 90,000 psi waterjet is capable of cutting through thick and hard materials such as metal, stone, and ceramics. The high pressure of the waterjet allows for a much faster and more efficient cutting process compared to other cutting methods.
Precision cutting: A high-pressure waterjet can cut with very high precision, making it useful for cutting complex shapes and designs. This is particularly useful in industries such as aerospace, where precision is critical for safety and performance.
Cleaning surfaces: A high-pressure waterjet can also be used for cleaning surfaces. The high pressure of the water can effectively remove stubborn dirt and grime from surfaces without damaging the underlying material.
Environmentally friendly: Waterjets use only water and abrasive material (if necessary) for cutting and cleaning, making them an environmentally friendly option compared to other cutting methods that may use chemicals or produce harmful fumes.
Overall, a 90,000 psi waterjet can be a valuable tool in various industries where precision, speed, and efficiency are critical.
Item | Part Number | Description | Item | Part Number | Description |
1 | 5146592 | Gasket, Topworks Support | 14 | 72162253 | Plunger |
2 | 20476377 | Support, Topworks | 15 | 5130091 | Hydraulic Seal Cartridge |
3 | 10118206 | O-Ring, 1.31×1.56× .13 | 16 | 72175989 | Bushing Retainer Flange |
4 | 5144514 | Hydraulic Cylinder | 17 | 72158494 | UHP Seal Assembly |
5 | 5098991 | Socket Head Screw, 3/8-16×3-3/4 | 18 | 72166738 | UHP Cylinder |
6 | 95688743 | Lock Washer, .38 | 19 | 72163802 | Liner |
7 | 72101190 | Piston Assembly | 20 | 20474325 | Stud, 1-1/8-12×18.31 |
8 | 10074771 | O-Ring, 5.25×5.50× .13 | 21 | 72170157 | Sealing Head Assembly |
9 | 5120092 | Backup Ring, 5.25×5.50× .13 | 22 | 72178493 | Flange Assembly |
10 | 72175997 | Hydraulic Cylinder Head | 23 | 20464590 | Flat Washer, 1.13 |
11 | 5097886 | Socket Head Screw, 3/4-16×2-1/4 | 24 | 20461761 | Hex Nut, 1-1/8-12 |
12 | 5144183 | Spacer Assembly, Proximity Switch | 25 | 20489339 | Adapter, JIC/Pipe, 50× .38 |
5144191 | O-Ring, .69× .88× .09 | 26 | 72176756 | O-Ring, 3.88×4.25× .19 | |
13 | 72141569 | Kit, Proximity Switch | 95119012 | Socket Head Screw, 1/4-20×1 | |
72134224 | Proximity Switch |
