49838220 HP Cylinder Nut for SL-VI100HP
Win Win waterjet provide many kinds of waterjet parts, OEM/ODM available
The 49838220 HP Cylinder Nut is a critical component in some types of waterjet pumps used for industrial applications. Its primary function is to secure the HP Cylinder of the pump to the main body of the pump and to create a tight seal between the cylinder and the body.
The HP Cylinder Nut is typically threaded and designed to screw onto the end of the HP Cylinder, securing it in place and compressing the seals or gaskets that create a seal between the cylinder and the main body of the pump. This tight seal is critical for preventing leaks and ensuring that the high-pressure water flow is delivered to the application with maximum efficiency.
The 49838220 HP Cylinder Nut is typically made of high-strength materials such as stainless steel or other alloys that can withstand the high pressure and corrosive properties of the water being pumped. It is also designed to be highly durable and resistant to wear and tear, helping to ensure reliable and efficient operation of the waterjet pump.
| Item | Part Number | Description | Item | Part Number | Description |
| 1 | 72119536 | HP Cylinder | 16 | 05120092 | Backup Ring, 5.25 x 5.50 |
| 2 | 05144506 | Ceramic Plunger | 17 | 10074771 | O-Ring, 5.25 x 5.50 x .13 |
| 3 | 72110979 | Sealing Head Assembly | 18 | 20413955 | Socket Head Screw, 3/4-16 x 3-1/4 |
| 4 | 20416445 | Hydraulic Cylinder Head | 19 | 05130224 | Proximity Switch, 20-250V AC/DC |
| 5 | 05149711 | HP Seal Assembly | 20 | 95119012 | Socket Head Screw, 1/4 x 20 x 1 |
| 7 | 49838220 | HP Cylinder Nut, HSEC | 21 | 05146576 | Piston Assembly |
| 8 | 05146584 | Hydraulic Cartridge Seal Assembly | 23 | 05144522 | Topworks Support |
| 9 | 05145099 | Bushing Retainer Flange | 25 | 05041058 | Socket Head Screw, 3/8-16 x 2-1/4 |
| 11 | 72110945 | Liner, HP Cylinder | 26 | 95688743 | Lock Washer, .38 |
| 12 | 10074920 | O-Ring, 1.75 x .94 x .09 | 27 | 10118206 | O-Ring, 1.31 x 1.56 x .13 |
| 13 | 80070352 | Jackbolt, 7/16-20 x 2.31 | 28 | 05144183 | Spacer Assembly, Proximity Switch |
| 14 | 05034798 | Retaining Ring | 05144191 | O-Ring, .69 x .88 x .09 | |
| 15 | 05144514 | Hydraulic Cylinder | 29 | 05146592 | Gasket, Topworks Support |
