waterjet cutting head parts 20453952 CAP, AUTOLINE® II, 60K, WATERJET GENUINE PART
| 20453949 | Autoline IITM Nozzle Assembly, .030 Wear Insert Figure |
| 20454108 | Autoline IITM Nozzle Assembly, .043 Wear Insert |
| 20453952 | Nozzle Cap |
| 20453958 | Nozzle Body |
| 20453064 | Wear Insert, .030 x .156 |
| 20453082 | Wear Insert, .043 x .156 |
| 20453964 | Feed Tube Assembly |
| 20453973 | Handle |
| 20433398 | Setscrew |
| 20453976 | T-Knob |
| 05138821 | O-Ring, .69 x .81 x .06 |
| 20445476 | O-Ring, .31 x .44 x .06 |
| 05087168 | Guard |
| 05081518 | O-Ring, .38 x .50 x .06 |
| 05077078 | O-Ring, .38 x .50 x .06 |
| 49885361 | Poly Tube, .38 |
1. Which nozzles are used for KMT waterjet cutting head?
The PRO Series features the superior HYPERTUBE Index Design for longer, more uniform wear preventing “focusing tube blow-out"
 | 0.030 x 3.0 / 0.76 mm x 76 mm 20477366 0.030 x 4.0 / 0.76 mm x 102 mm 20477382 0.033 x 4.0 / 0.84 mm x 102 mm 20490760 0.040 x 3.0 / 1.02 mm x 76 mm 20486133* 0.040 x 4.0 / 1.02 mm x 102 mm 20486166* 0.043 x 3.0 / 1.10 mm x 76 mm 20477386 0.043 x 4.0 / 1.10 mm x 102 mm 20477395 0.045 x 3.0 / 1.14 mm x 76 mm 20486151* 0.045 x 4.0 / 1.14 mm x 102 mm 20486158 0.048 x 4.0 / 1.22 mm x 102 mm 20490768 |
ROCTEC® 100 waterjet cutting head nozzle
| 0.021 x 3.13 / 0.53 mm x 79 mm 20451227* 0.025 x 3.13 / 0.63 mm x 79 mm 20452309* 0.030 x 3.13 / 0.76 mm x 79 mm 10126969 0.036 x 3.13 / 0.91 mm x 79 mm 80075252 0.039 x 3.13 / 0.99 mm x 79 mm 49833593* 0.040 x 3.13 / 1.02 mm x 79 mm 49835390 0.043 x 3.13 / 1.10 mm x 79 mm 10126928 0.052 x 3.13 / 1.32 mm x 79 mm 05117528 0.058 x 3.13 / 1.47 mm x 79 mm 05051891* 0.063 x 3.13 / 1.60 mm x 79 mm 10126936 |
ROCTEC® 500
 | 0.021 x 2.0 / 0.53 mm x 50 mm 05097928 0.030 x 3.13 / 0.76 mm x 79 mm 05097944 0.036 x 3.13 / 0.91 mm x 79 mm 05116652 0.043 x 3.13 / 1.10 mm x 79 mm 05097936 0.093 x 3.13 / 2.36 mm x 79 mm 05130927* |
2. Which model orifice suit for KMT waterjet cutting head ?
1. AUTOLINE PRO 6,200 bar Diamond Orifice
 | 0.004" / 0.10 mm 20481704 0.005" / 0.12 mm 20481705 0.006" / 0.15 mm 20481706 0.007" / 0.17 mm 20481707 0.008" / 0.20 mm 20481708 0.009" / 0.23 mm 20481709 0.010" / 0.25 mm 20481710 0.011" / 0.28 mm 20481711* 0.012" / 0.30 mm 20481712 0.013" / 0.33 mm 20481713* 0.014" / 0.35 mm 20481714 0.015" / 0.38 mm 20481715* 0.016" / 0.40 mm 20481716 0.017" / 0.43 mm 20481717* 0.018" / 0.46 mm 20481718* 0.019" / 0.48 mm 20481719* 0.020" / 0.51 mm 20481720* 0.021" / 0.53 mm 20481721* 0.022" / 0.56 mm 20481722* |
2. AUTOLINE I & II 4,100 bar For True Alignment & Maximum Performance waterjet cutting head Diamond Orifice
  | 0.004" / 0.10 mm 20448625* 0.007" / 0.17 mm 05063847 0.008" / 0.20 mm 05112537 0.009" / 0.23 mm 05084504 0.010" / 0.25 mm 05077029 0.011" / 0.28 mm 05101753 0.012" / 0.30 mm 05077300 0.013" / 0.33 mm 05136098 0.014" / 0.35 mm 05077037 0.015" / 0.38 mm 80075781* 0.016" / 0.40 mm 05121512 0.018" / 0.46 mm 05114905* 0.019" / 0.48 mm 80086663* 0.020" / 0.51 mm 05114897 |
3. Sapphire Orifice
  | 0.007" / 0.17 mm 05109079* 0.008" / 0.20 mm 05109087* 0.009" / 0.23 mm 05109095* 0.010" / 0.25 mm 05109103* 0.011" / 0.28 mm 05109111* 0.012" / 0.30 mm 05109129* 0.013" / 0.33 mm 20412569* 0.014" / 0.35 mm 05109137* 0.016" / 0.40 mm 20448541* 0.018" / 0.46 mm 05114913* 0.019" / 0.48 mm 80086671* 0.020" / 0.51 mm 05114921 |
4. Orifices for Pure Water Cutting 4,100 bar Diamond Orifice
  | 0.003" / 0.07 mm 49888852 0.004" / 0.10 mm 49888860 0.005" / 0.12 mm 49888878 0.006" / 0.15 mm 49888886 0.007" / 0.17 mm 49888894 0.008" / 0.20 mm 49888902 0.009" / 0.23 mm 49888910 0.010" / 0.25 mm 49888928 0.012" / 0.30 mm 49888936 0.013" / 0.33 mm 49836786* 0.014" / 0.35 mm 49888944 0.015" / 0.38 mm 49888951 0.016" / 0.40 mm 49888969 0.018" / 0.46 mm 49888977 0.019" / 0.48 mm 20436198* 0.020" / 0.51 mm 49888985 0.022" / 0.56 mm 49888993 |
5. waterjet cutting head Sapphire Orifice
  | 0.003" / 0.07 mm A2260003* 0.004" / 0.10 mm 49863574 0.005" / 0.12 mm 49863582 0.006" / 0.15 mm 91954073 0.007" / 0.17 mm 49863590 0.008" / 0.20 mm 49865850 0.009" / 0.23 mm 49863608 0.010" / 0.25 mm 49863616 0.011" / 0.28 mm A2260011* 0.012" / 0.30 mm 49863624 0.013" / 0.33 mm A2260013* 0.014" / 0.35 mm 49863632 0.015" / 0.38 mm A2260015 0.016" / 0.40 mm A2260016 0.018" / 0.46 mm A2260018* 0.019" / 0.48 mm A2260019* 0.020" / 0.51 mm A2260020* 0.022" / 0.56 mm A2260022* |
6.4,100 bar Diamond Orifice
  | 0.005" / 0.12 mm 72113688 0.006" / 0.15 mm 72132350 0.007" / 0.17 mm 72113753 0.007" / 0.17 mm, 3/8-24 Thread 72113680 0.008" / 0.20 mm 72132358 0.009" / 0.23 mm 72136231 0.010" / 0.25 mm 72136249 0.011" / 0.28 mm 72136256 |
