20449078 hydraulic hose for waterjet intensifier pump

20449078 hydraulic hose for waterjet intensifier pump

Product Item:20449078
Product Name:H-20 waterjet part
Manufacturer: Win Win Waterjet
  • Product Detail

20449078 hydraulic hose for waterjet intensifier pump

Win Win waterjet provide many kinds of waterjet parts, OEM/ODM available

The Hydraulic Hose 20449078 is a component of a waterjet system that is responsible for transmitting hydraulic fluid between the pump and other hydraulic system components such as the cutting head or intensifier. Hydraulic hoses are used in many applications where high-pressure fluid transfer is required, such as in hydraulic machinery and equipment.


In a waterjet system, the hydraulic hose is typically used to transfer hydraulic oil from the pump to the intensifier, which is responsible for generating the high-pressure water used for cutting. The hydraulic hose is designed to withstand the high pressure and flow rates of the hydraulic fluid used in the system, typically ranging from several hundred to several thousand pounds per square inch (psi) of pressure.


The hydraulic hose is typically made of a flexible, reinforced material such as rubber or thermoplastic, and is designed to withstand the rigors of high-pressure fluid transfer. They are usually connected to the pump and other components using fittings or connectors that are designed to provide a secure and leak-free connection.


It is important to regularly inspect and maintain the hydraulic hose to ensure that it is in good condition and free from damage or wear. Damaged or worn hydraulic hoses can lead to leaks or other issues that can affect the performance and safety of the waterjet system.


ItemPart NumberDescriptionItemPart NumberDescription
120458305End Cap 1220458062Plunger Retainer
220457399High Pressure Cylinder1320458869Hydraulic Piston Assembly
320458299End Bell, LH
20457966Hydraulic Piston
420458302End Bell, RH
20458821Rebuild Kit, Piston Rings
520458191Tie Rod
20460216Seal
620460489Hex Nut 1420458170Spacer, Hydraulic Seal
720457414Hydraulic Cylinder1520458908Sealing Head Assembly
820458161Backup Sleeve1620460252Snap Ring
920458773Rebuild Kit, High Pressure Seal Assembly 1705202930Snap Ring

20457990Seal Buttress1820457267Inlet Water Nipple

20458113High Pressure Seal
20457159Adapter, Quick Disconnect

20457393Seal Hoop
20459025O-Ring, Quick Disconnect

20460108O-Ring1120457912Plunger
1020458797Rebuild Kit, Hydraulic Seal Assembly
