10079465 Tee for 100HP waterjet cutting pump
Win Win waterjet provide many kinds of waterjet parts, OEM/ODM available
The 10079465 tee is a component used in water spray pumps to divide high-pressure water flow into two independent paths. A tee is usually located in the hydraulic system of a pump and is responsible for guiding water flow to different parts of the system, such as the cutting head and intensifier.
The function of a tee is to provide a reliable and effective way to divide high-pressure water flow into two independent paths. A tee joint typically consists of a T-shaped joint with three openings, allowing high-pressure water to flow in through one opening and out through two separate openings.
By dividing the water flow into two independent paths, the tee helps to ensure that the spray pump can efficiently and effectively deliver high-pressure water to different parts of the system, such as cutting heads and enhancers. This helps ensure precise cutting and reduces the risk of damage to the cutting head or other components of the water jet cutting system
Item | Part Number | Description | Item | Part Number | Description |
1 | 72119536 | HP Cylinder | 16 | 05120092 | Backup Ring, 5.25 x 5.50 |
2 | 05144506 | Ceramic Plunger | 17 | 10074771 | O-Ring, 5.25 x 5.50 x .13 |
3 | 72110979 | Sealing Head Assembly | 18 | 20413955 | Socket Head Screw, 3/4-16 x 3-1/4 |
4 | 20416445 | Hydraulic Cylinder Head | 19 | 05130224 | Proximity Switch, 20-250V AC/DC |
5 | 05149711 | HP Seal Assembly | 20 | 95119012 | Socket Head Screw, 1/4 x 20 x 1 |
7 | 49838220 | HP Cylinder Nut, HSEC | 21 | 05146576 | Piston Assembly |
8 | 05146584 | Hydraulic Cartridge Seal Assembly | 23 | 05144522 | Topworks Support |
9 | 05145099 | Bushing Retainer Flange | 25 | 05041058 | Socket Head Screw, 3/8-16 x 2-1/4 |
11 | 72110945 | Liner, HP Cylinder | 26 | 95688743 | Lock Washer, .38 |
12 | 10074920 | O-Ring, 1.75 x .94 x .09 | 27 | 10118206 | O-Ring, 1.31 x 1.56 x .13 |
13 | 80070352 | Jackbolt, 7/16-20 x 2.31 | 28 | 05144183 | Spacer Assembly, Proximity Switch |
14 | 05034798 | Retaining Ring | 05144191 | O-Ring, .69 x .88 x .09 | |
15 | 05144514 | Hydraulic Cylinder | 29 | 05146592 | Gasket, Topworks Support |
