05116603 Discharge Poppet Valve for 100HP waterjet intensifier pump

05116603 Discharge Poppet Valve for 100HP waterjet intensifier pump

Product Item:05116603 Discharge Poppet Valve
Name:100HP waterjet pump spare part
Manufacturer: Win Win waterjet
  • Product Detail

05116603 Discharge Poppet Valve

Win Win waterjet provide many kinds of waterjet parts, OEM/ODM available

A discharge poppet valve is a type of valve used in waterjet pumps to control the flow of water through the system. Specifically, this type of valve is responsible for regulating the flow of high-pressure water from the pump to the cutting head.

In a waterjet pump, water is pressurized to extremely high levels before being discharged through a nozzle to create a high-speed jet of water for cutting, cleaning, or other applications. The discharge poppet valve is located between the pump and the cutting head and is designed to control the pressure and flow rate of the water as it passes through.

The poppet valve typically consists of a spring-loaded piston or ball that is held in place by a seat. When water flows through the valve, it creates pressure on the piston or ball, which compresses the spring and opens the valve to allow water to flow through. When the pressure drops or the flow rate decreases, the spring pushes the piston or ball back into place, closing the valve and maintaining pressure in the system.


100hp waterjet.png

ItemPart
Number
Description ItemPart
Number
Description
172119536HP Cylinder 1605120092Backup Ring, 5.25 x 5.50
205144506Ceramic Plunger1710074771O-Ring, 5.25 x 5.50 x .13
372110979Sealing Head Assembly 1820413955Socket Head Screw, 3/4-16 x 3-1/4
420416445Hydraulic Cylinder Head1905130224Proximity Switch, 20-250V AC/DC
505149711HP Seal Assembly2095119012Socket Head Screw, 1/4 x 20 x 1
749838220HP Cylinder Nut, HSEC2105146576Piston Assembly
805146584Hydraulic Cartridge Seal Assembly2305144522Topworks Support
905145099Bushing Retainer Flange 2505041058Socket Head Screw, 3/8-16 x 2-1/4
1172110945Liner, HP Cylinder 2695688743Lock Washer, .38
1210074920O-Ring, 1.75 x .94 x .092710118206O-Ring, 1.31 x 1.56 x .13
1380070352Jackbolt, 7/16-20 x 2.31 2805144183Spacer Assembly, Proximity Switch
1405034798Retaining Ring
05144191O-Ring, .69 x .88 x .09
1505144514Hydraulic Cylinder2905146592Gasket, Topworks Support
